P8600 喷油泵
P8600 injection
pump

Element dia: 12 ~ 14mm, 16mm (under developing)
Cam lift: 14 ~15mm
Cylinder distance: 38mm
Cylinder No.:  6

Rotation speed: 1200rpm
Governor: RSV, RQV-K

Installation: Four lug & End flange with ancilary shoring



8600 type pump is for heavy truck &construction usage.
